Evidence for Liquid Surface Water on Mars
A Northern Meridiani Venting Site


An active venting crater located 3°N 3.5°E in northern Meridiani at the border to Arabia about 480 km south of the Pillars. The composite image is 200% original size, therfore 50 m/pix. The images were randomly shot over about one year. Here the visual ones are presented in a sequence of one ejection cycle. At first we see the bright crater with bright ejecta, either ice or salt from evaporated water.

Then, in the second frame, a large cloud covers the crater. In the third frame we see black ejecta around the crater about the size the cloud had before, as expected, as the cloud settled and triggered a chemical reaction with the martian soil. The crater is still bright because it still emits water clouds. In the last frame the venting is just at lower activity level than before.

TS4.gif The cloud of the second frame is shown here in 300% of the above size (600% of the original Themis image) in different histogram adjustments. We still see the crater and the cloud is wind drifted to the east.
The visual image with the black ejecta combined with a thermal image looks almost the same. Main distinction are some black craters in the thermal one. It is probably due to evaporating water that cools the ground. Notable is the still bright (hot) interior of the eruption crater. It indicates continuous activity powered by subsurface vulcanism. This crater is probably a pseudocrater. The lack of any topography-related shadow points to such a flat short-cone typ of crater, too.

This albedo feature is even visible in a Viking Orbiter image of some 25 years ago. Above the following Themis images were used:

I01635005 2002-04-28 INA 51 LST  15.4 SL    5 white cloud over crater
I01804002 2002-05-12
LST   3.5
SL  12  thermal
I04606009 2002-12-28 INA 73 LST  16.8
SL 115
bright ejecta
I06466022 2003-05-30 INA 82 LST  17.4 SL 194 black ejecta
INA = elevation of sun, 0 = noon
LST = local true solar time
SL = Solar Longitude (what season of martian year)
